Hobbypower 10A Brushed Motor Speed Controller for RC Car/Boat – No Brake
Hobbypower 10A Brushed Motor Speed Controller for RC Car/Boat – No Brake
The Hobbypower 10A Brushed ESC is a simple forward/reverse electronic speed controller designed for small RC cars and boats. It supports a range of brushed motors from 130 to 380 size and runs on 2S LiPo or 4-7 cell NiMH/NiCd packs. With a continuous 10A rating and no brake function, it's a lightweight, no-frills option for basic RC builds.
What This ESC Does
This speed controller provides two functions: forward and reverse. There is no brake – when you center the throttle, the motor coasts freely. It accepts a standard PPM signal from your receiver and drives the motor using a 2KHz PWM frequency. The BEC output is 5V at 1A, enough to power a small receiver and a couple of servos.
Specs at a Glance
| Continuous Current | 10A |
| Max Current (20A for <30s) | 20A |
| Pulse Current (30A for <5s) | 30A |
| BEC Output | 5V / 1A |
| Input Signal | PPM (PWM 2KHz) |
| Battery Compatibility | 2S LiPo, 4-7 cell NiMH/NiCd |
| Motor Support | 130/180/260/280/380 Brushed |
| Dimensions | 0.91 x 0.83 x 0.24 inches |
| Weight | 0.32 ounces (ESC only) |
Which Motors Work With It
The ESC is compatible with commonly used brushed motors: 130, 180, 260, 280, and 380 sizes. These are found in many small RC cars, boats, and planes. If you're building a lightweight project or replacing a broken controller, this unit fits the bill. Check the current draw of your motor – anything under 10A continuous is fine. For brief bursts, the ESC can handle up to 20A for 30 seconds and 30A for 5 seconds.
Common Questions
Does this ESC have a brake?
No. The controller only offers forward and reverse. There is no brake function, so the motor will stop by friction or you must manually reverse to slow down.
What batteries can I use?
You can use a 2S LiPo (7.4V) or a 4 to 7 cell NiMH or NiCd pack (4.8V to 8.4V). Do not use 3S LiPo or higher – the voltage will damage the ESC.
Is the ESC waterproof?
The supplied information does not specify waterproofing. Treat it as not waterproof unless stated otherwise. Keep it dry.
What's in the box?
You get one 10A ESC with wires pre-soldered. No connectors or instruction sheet are included in the package.
Who Should Use This
This ESC is ideal for hobbyists who need a simple, lightweight speed controller for a small RC car or boat with a brushed motor. Because it lacks a brake, it suits applications where coasting is fine – like boats or cars on low-traction surfaces. If you need braking, look for an ESC with brake function.
